Conductor Head
Architectural appeal is the most common purpose for the use of Conductor Heads, also known as Collector Boxes, Leader Heads, and Scupper Boxes. Conductor Heads add the finishing touch to a well installed gutter system. These items are custom fabricated.
The following collection boxes display the stock width measurement of 15". This is customized to your installation. If you have any dimension questions, please get in touch! If you require a box size greater than 15" a custom template fee may be charged.
THE ROYAL CONDUCTOR
DIMENSIONS:
Length: 15 1/2″
Width: 15″
Depth: 9 5/8″
Outlet: 3″ or 4″
Dimensions (Mini):
Length: 11.5″
Width: 12.5″
THE STANDARD CONDUCTOR
DIMENSIONS:
3″ Conductor Head
Length: 9 3/4″
Width: 11 5/8″
Depth: 7 1/4″
This is a custom fabricated item.
4″ Conductor Head
Length: 9 3/4″
Width: 12 3/4″
THE CHURCHILL CONDUCTOR
DIMENSIONS:
Length: 20″
Width: 17″
Depth: 9″
Inset: 5″ x 8″
THE WINDSOR CONDUCTOR
DIMENSIONS:
Length: 13″
Width: 15″
Depth: 9 1/2″
Outlet: 3×4″
THE STRATFORD CONDUCTOR
DIMENSIONS:
Length: 18 1/2″
Width: 18 1/2″
Depth: 11 3/4″
Outlet: 2×3″ or 3×4″
THE FEDERAL CONDUCTOR
DIMENSIONS:
Length: 8″
Width: 12 7/8″
Depth: 8″ 1/8″
Available in 16 oz. Copper
THE ESSEX CONDUCTOR
DIMENSIONS:
Length: 10″
Width: 13″
Depth: 8 1/2″
Available in 16 oz. Copper
THE PARISIAN CONDUCTOR
DIMENSIONS:
Length: 18″
Width: 15 1/4″
Depth: 9″
Available in 16 oz. Copper
Length: 9 3/4″
Width: 12 3/4″
